Beolab 7.1 was simply the most powerful stereo speakers ever developed for TV. Packed with advanced technology and designed to fit under a BeoVision 7 or BeoVision 4 screen, they both have six driver units, each powered by an ICEpower amplifier. Delivering a weighty 750 watts, it produces quality that far exceeds anything you'd expect from a television speaker.
Beolab 7.1
2006
Dimensions
Dimensions CTV: W x H x D 100 x 11 x 21 cm
Weight Approx. 10 kg
For more information on measurements please see the following documents:
[<a href=../DocName/At..LPID6HXHZU/$file/DIM_BeoLab_7-1.pdf
target=_blank>"Dimensions"</a>] or [<a
href=../DocName/At..LPID6NSH2G/$file/DIM_BeoLab_7-1US.pdf target=_blank>"Dimensions -
Inches"</a>]
Specifications
Cabinet finish Aluminium cabinet coated with hardwearing black soft-touch
lacquer. Speaker grill in anodised aluminium in following
colours: Silver, Black, Dark Grey, Red, Blue, Golden
Power consumption IEC65: 36 watt
Typical: 20 watt
Stand-by: 0.2 watt
Power amplifiers (per channel) 3 x 125 watts, Class D, ICEpower®
Long-term maximum output
power
per amplifier Bass: 120 watts/8 ohm
Midrange: 120 watts/8 ohm
Treble: 120 watts/8 ohm
Effective Frequency range 56 - 27,300 Hz
Crossover frequencies 250 Hz and 4.000 Hz
Cabinet principle Bass: Bass reflex
Midrange/Treble: Closed box
Net volume, bass 4.2 litres (per side)
Net volume, midrange 0.8 litres (per side)
Magnetically shielded No
Woofer 101,6 mm (4")
Midrange 76,2 mm (3")
Tweeter 19 mm (¾")
Bass equalization ABL (Adaptive Bass Linearization)
Input sensitivity (Power Link) 88dB @ 125 mV SPL
Indicator (for service use only) 1 tri-colour LED. Green for On, Red for Off, Orange for
Protection mode
Operation Free or Wall position
Protection Thermal protection.
Connections
Power Link 1 (use Semi-Balanced PL cable type mkIII, or fully mounted PL cable)
Mains 1 input, 1 output (not US version)
Market specifications
Type Market Voltage
6210 Australia, Austria, Bahrain, Belgium, China
Croatia, Czech Repub., Denmark, Egypt, Finland, France,
Germany, Greece, Holland, Hong Kong, Hungary,
Indonesia, Israel, Italy, Kuwait, Lebanon, Malaysia,
Marocco, Norway, Oman, Poland, Portugal, Qatar,
Russia, Saudi Arabia, Singapore, Slovak Rep., Slovenia,
South Africa, Spain, Sweden, Switzerland, Thailand,
Turkey, United Arab Emirates, United Kingdom
220-240V
6212 USA, Canada, Mexico, Taiwan 100-120 V
Accessories
Bracket for BeoLab7-1 Type 2182 (1218266)
Wall bracket (Black) Type 2172 (1217266)
Table Stand (Aluminium) Type 2176 (1217611)
Recommended mounting of BeoLab 7-1
on wall bracket type 2172:
6 Months Parts
3 Months Labour
3 STAR - Our Approved Used Bang & Olufsen 3* products are in above-average condition for their age. They may have minor cosmetic damage and visable signs of normal use
Mains lead
